SV 105A Hand-arm Triaxial Accelerometer

[ Svantek ]

SV 105A Hand-arm Triaxial Accelerometer

[ Vibrations ]

  • Best Selling
  • Hardware
  • Software
  • Transmission
  • Parameters
  • triaxial
  • accelerometers
  • mems

- Meets ISO 8041 and ISO 5349 - Low-power consumption - No disturbance to operator - Dedicated to SV 106 instrument - TEDS memory

The SV 105A is a low cost triaxial hand-arm accelerometer based on MEMS (Micro Electro Mechanical System) technology. It is designed for human vibration measurements performed according to ISO 8041:2005. The accelerometer is ideally suited for with our SV 106 six channel analyser. Calibration of the vibration measurement setup including the SV 105A can be done using the accelerometer sensitivity written into the TEDS memory or by using a vibration calibrator with a SA 105 adapter option.
